¤····Subject: Mo Mars 2016

Received: 14 May 2017 at 12:37 JST



Mars images in July 2016.



http://www.kwasan.kyoto-u.ac.jp/~cmo/cmons/2016/160731/Mo31July16.jpg

http://www.kwasan.kyoto-u.ac.jp/~cmo/cmons/2016/160729/Mo29July16.jpg

http://www.kwasan.kyoto-u.ac.jp/~cmo/cmons/2016/160727/Mo27July16.jpg

http://www.kwasan.kyoto-u.ac.jp/~cmo/cmons/2016/160722/Mo22July16.jpg

http://www.kwasan.kyoto-u.ac.jp/~cmo/cmons/2016/160717/Mo17July16.jpg

http://www.kwasan.kyoto-u.ac.jp/~cmo/cmons/2016/160705/Mo05July16.jpg

http://www.kwasan.kyoto-u.ac.jp/~cmo/cmons/2016/160704/Mo04July16.jpg

http://www.kwasan.kyoto-u.ac.jp/~cmo/cmons/2016/160703/Mo03July16.jpg



http://www.kwasan.kyoto-u.ac.jp/~cmo/cmons/2016/160630/Mo30June16.jpg





Yukio MORITA (Hiroshima, JAPAN)







¤····Subject: Jupiter, Ganymede & Io 2017.04.28

Received: 12 May 2017 at 15:38 JST



Dears,

Under good conditions, Jupiter along with Ganymede & Io showing details:




http://www.astrosurf.com/delcroix/images/j2017-04-28_22-59-06_rgb_md_nolegend.png






http://www.astrosurf.com/delcroix/images/j2017-04-28_23-27-12_ir685_md_nolegend.png


From Sud to North, we can see:
- the south polar red spot
- 3 white SSTB ovals
- The dark "STB spectre" (both in visible and methane absorption band) rising
- rifts setting in SEB
- a very dark formation south of NEB, at meridian (corresponding to a hot spot)
- perturbations rising in NEB
- a very orange NNTB

All detailed images:
RGB
: http://www.astrosurf.com/delcroix/images/planches/j2017-04-28_22-59-06_rgb_md.png

IR:
http://www.astrosurf.com/delcroix/images/planches/j2017-04-28_22-43-36_ir685_md.png

http://www.astrosurf.com/delcroix/images/planches/j2017-04-28_23-27-12_ir685_md.png

http://www.astrosurf.com/delcroix/images/planches/j2017-04-28_23-39-06_ir685_md.png

CH4:




 http://www.astrosurf.com/delcroix/images/planches/j2017-04-28_23-12-42_ch4_md.png

Individual color layers:
http://www.astrosurf.com/delcroix/images/planches/j2017-04-28_22-55-36_r_md.png

http://www.astrosurf.com/delcroix/images/planches/j2017-04-28_22-59-06_g_md.png

http://www.astrosurf.com/delcroix/images/planches/j2017-04-28_23-02-36_b_md.png

Steady skies,



Marc DELCROIX (Tournefeuille, FRANCE)

http://astrosurf.com/delcroix







¤····Subject: Jupiter 7-May-2017

Received: 9 May 2017 at 18:26 JST



Hi Guys Just a little improvement in the seeing this evening. My attention was drawn to the pink clouds in the EZ .






Best wishes



Dave TYLER (Bucks, the UK)

www.david-tyler.com







¤····Subject: solar images April / May 2017

Received: 5 May 2017 at 01:48 JST



Hi Guys here are a few solar images of recent happenings. 19th Apr caught the returning of AR2644, now named AR2651. Pity the weather did not allow me to follow it. The tiny AR2652 can be seen close to the limb and left of AR2651.








AR 2654 surged in size in a very short time, on the 2nd May and is still on view.






Best Wishes



Dave TYLER (Bucks, the UK)

www.david-tyler.com







¤····Subject: Jupiter, Io, Europe & Callisto 2017.04.23

Received: 4 May 2017 at 15:59 JST



Dears,

Under conditions sometimes good, despite clouds covering the planet on some of my acquisitions, Jupiter and 3 satellites (with details on Io & Callisto). One can see, from South to North:

- a red spot in the south polar zone, around meridian, bright in methane absorption band filter.

- "STB spectre" rising on the left in the STB, dark in methane filter

- Great Red Spot setting at beginning of session, hardly visible on the limb, followed by its perturbations

- a double bright eruptive spot mid of SEB, around meridian at beginning of the session

- dark zone in methane filter in NEB, which seems to be strangely related to a bright spot in visible bands

Best resolved images are R from 22h31UT and IR from 23h04UT.

IR:


http://www.astrosurf.com/delcroix/images/planches/j2017-04-23_22-19-24_ir685_md.png
http://www.astrosurf.com/delcroix/images/planches/j2017-04-23_23-04-00_ir685_md.png

RGB (first one saved despite very shortened G and B layers due to the clouds) :


http://www.astrosurf.com/delcroix/images/planches/j2017-04-23_22-34-48_rgb_md.png




http://www.astrosurf.com/delcroix/images/planches/j2017-04-23_23-27-00_rgb_md.png





CH4:

http://www.astrosurf.com/delcroix/images/planches/j2017-04-23_22-46-00_ch4_md.png
http://www.astrosurf.com/delcroix/images/planches/j2017-04-23_23-41-36_ch4_md.png



R, G et B (first R and last B rather detailed):

http://www.astrosurf.com/delcroix/images/planches/j2017-04-23_22-31-12_r_md.png
http://www.astrosurf.com/delcroix/images/planches/j2017-04-23_22-34-00_g_md.png
http://www.astrosurf.com/delcroix/images/planches/j2017-04-23_22-39-18_b_md.png

http://www.astrosurf.com/delcroix/images/planches/j2017-04-23_23-22-42_r_md.png
http://www.astrosurf.com/delcroix/images/planches/j2017-04-23_23-27-00_g_md.png
http://www.astrosurf.com/delcroix/images/planches/j2017-04-23_23-31-12_b_md.png

No impact flash detected by DeTeCt ( [url]http://www.astrosurf.com/planetessaf/doc/project_detect.shtml[/url] )

Steady skies,


PS: IR, RGB and CH4 images attached in this first mail, color layers images will be sent separately.


Marc DELCROIX (Tournefeuille, FRANCE)

http://astrosurf.com/delcroix







¤····Subject: Jupiter in Quadtych

Received: 3 May 2017 at 01:35 JST



Jupiter in Quadtych.

These are clean RGB pictures (no ir or R as luminance).

Nice to see is the Great Red Spot is turning away.

Despite the low altitude of Jupiter (30 degrees), many details are visible.





Telescope C14

Chroma RGB filters

Date 2017/4/8

Enschede Netherlands



Richard BOSMAN (NETHERLANDS)







¤····Subject: Jupiter images 22-Apr-2017

Received: 29 April 2017 at 04:34 JST



Hi Guys borderline seeing in Green and Blue, but better in Red. The row of black dots, shown more clearly on the mono images, caught my eye. I thought no, nothing like the Shoemaker Levy 9 impacts , the results of which which I observed with an eyepiece over several twilight evenings evenings in July 1994.










Best wishes



Dave TYLER (Bucks, the UK)

www.david-tyler.com







¤····Subject: Jupiter 23-April-2017

Received: 25 April 2017 at 21:01 JST



Hi Guys not quite so frustrating low altitude seeing this evening, good enough to give AS3 and R6 something to work on. It was only good for about an hour, going from poor to good in a matter of seconds and likewise from good to poor.








Best wishes



Dave TYLER (Bucks, the UK)

www.david-tyler.com







¤····Subject: Jupiter, Io & Ganymede 2017.04.17

Received: 23 April 2017 at 08:42 JST



Dears,

Jupiter, Io & Ganymede, under average conditions. IR is good enough to show GRS rising, oval BA at meridian followed by a chain of dark spot, and details on Ganymede.



IR:


http://www.astrosurf.com/delcroix/images/planches/j2017-04-17_23-10-54_ir685_md.png
http://www.astrosurf.com/delcroix/images/planches/j2017-04-17_22-27-42_ir685_md.png



Methane absorption band:


http://www.astrosurf.com/delcroix/images/planches/j2017-04-17_22-57-00_ch4_md.png



RGB, and color layers:


http://www.astrosurf.com/delcroix/images/planches/j2017-04-17_22-42-18_rgb_md.png

http://www.astrosurf.com/delcroix/images/planches/j2017-04-17_22-37-48_r_md.png
http://www.astrosurf.com/delcroix/images/planches/j2017-04-17_22-42-18_g_md.png
http://www.astrosurf.com/delcroix/images/planches/j2017-04-17_22-46-48_b_md.png

Steady skies,



Marc DELCROIX (Tournefeuille, FRANCE)

http://astrosurf.com/delcroix







¤····Subject: Jupiter, Io & Europa 2017.04.13

Received: 21 April 2017 at 06:33 JST



Dears,

Under correct conditions, Jupiter and its two closest Galilean satellites, with GRS transiting at meridian (bright in methane) and "STB Ghost" (very dark in methane) passing by just South. One one methane image other very dark material is passing North of GRS, making this look as if it would be a unique feature which split on both side of GRS (which I doubt).

In NEB, a small bright spot at meridian, and a larger circled white oval in the polar area more North (bright in methane).



In IR:


http://www.astrosurf.com/delcroix/images/planches/j2017-04-13_21-56-24_ir685_md.png
http://www.astrosurf.com/delcroix/images/planches/j2017-04-13_22-39-30_ir685_md.png



In methane absorption band:


http://www.astrosurf.com/delcroix/images/planches/j2017-04-13_22-26-00_ch4_md.png
http://www.astrosurf.com/delcroix/images/planches/j2017-04-13_23-05-30_ch4_md.png



An average RGB:


http://www.astrosurf.com/delcroix/images/planches/j2017-04-13_22-53-18_rgb_md.png

I
ts color layers:
http://www.astrosurf.com/delcroix/images/planches/j2017-04-13_22-49-30_r_md.png
http://www.astrosurf.com/delcroix/images/planches/j2017-04-13_22-53-18_g_md.png
http://www.astrosurf.com/delcroix/images/planches/j2017-04-13_22-57-12_b_md.png

Steady skies,



Marc DELCROIX (Tournefeuille, FRANCE)

http://astrosurf.com/delcroix







¤····Subject: Jupiter 2017.04.12

Received: 19 April 2017 at 06:45 JST



Dears,

Under bad conditions, with oval BA rising:




In CH4: http://www.astrosurf.com/delcroix/images/planches/j2017-04-12_23-08-54_ch4_md.png
In IR: http://www.astrosurf.com/delcroix/images/planches/j2017-04-12_22-42-00_ir685_md.png
In RGB: http://www.astrosurf.com/delcroix/images/planches/j2017-04-12_22-56-36_rgb_md.png



Individual color layers:
http://www.astrosurf.com/delcroix/images/planches/j2017-04-12_22-53-06_r_md.png
http://www.astrosurf.com/delcroix/images/planches/j2017-04-12_22-56-36_g_md.png
http://www.astrosurf.com/delcroix/images/planches/j2017-04-12_23-00-12_b_md.png

Steadier skies,



Marc DELCROIX (Tournefeuille, FRANCE)

http://astrosurf.com/delcroix







¤····Subject: Jupiter, Io & Europa 2017.04.09

Received: 18 April 2017 at 07:43 JST



Dears,

5th Jupiter observation session for this opposition (I started a bit late), the results rather correct surprised me, I thought it would turn out much worse ... Is this thanks to the nice cocktail Winjupos derotation + Autostakkert 3 ?

Two interesting things to be seen in the atmosphere, here, both left of central meridian: the dark feature in the bright STrZ (also dark in methane absorption band), and a small bright eruption in the NEB.



RGB:




http://www.astrosurf.com/delcroix/images/planches/j2017-04-09_22-57-12_rgb_md.png



In IR:




http://www.astrosurf.com/delcroix/images/planches/j2017-04-09_22-42-48_ir685_md.png





In methane absorption band:




http://www.astrosurf.com/delcroix/images/planches/j2017-04-09_23-12-00_ch4_md.png



Individual color layers:
http://www.astrosurf.com/delcroix/images/planches/j2017-04-09_22-52-42_r_md.png

http://www.astrosurf.com/delcroix/images/planches/j2017-04-09_22-57-12_g_md.png

http://www.astrosurf.com/delcroix/images/planches/j2017-04-09_23-01-48_b_md.png

Steady skies,



Marc DELCROIX (Tournefeuille, FRANCE)

http://astrosurf.com/delcroix







¤····Subject: Mars: April 14, 2017

Received: 16 April 2017 at 14:21 JST



Hi,

I have attached my latest image of Mars April 14, 2017 at 23:30 UT.



 Thanks,

http://www.kwasan.kyoto-u.ac.jp/~cmo/cmons/2016/170414/FMl14Apr17.jpg



 Frank J MELILLO (Holtsville, NY







¤····Subject: Mars 7th April and Jupiter 8th April 2017

Received: 14 April 2017 at 19:13 JST



Hi,
A couple of very different sessions last weekend.



On the Friday (7th April) Mars 10.5 months after opposition at 4.1" in low in the West just after sunset with multiple overlapping images during preview- rescued by edge quality sort in AS!3, then the following day Jupiter one day after opposition in very good seeing which was much easier to process.



Jupiter with colour camera and also with ZWO CH4 filter.





Details on both images and see the images also here;
http://www.skyinspector.co.uk/mars-and-venus
http://www.skyinspector.co.uk/jupiter

Cheers
http://www.kwasan.kyoto-u.ac.jp/~cmo/cmons/2016/170407/MLw07Apr17.jpg



Martin LEWIS (St Albans, the UK)
